供應(yīng)德國deltafilter過濾器
Type Flow rate* at 50-100 µm In-/Outlet Drain Filter area
、濾芯 DELTA-SKS-02 5 m³/h PN16
DN25
R 3/4" BSP inner thread
470 cm²
、濾芯 DELTA-SKS-04 11 m³/h PN16
DN40
R 3/4" BSP inner thread
470 cm²
、濾芯 DELTA-SKS-05 18 m³/h PN16
DN50
R 3/4" BSP inner thread
980 cm²
、濾芯 DELTA-SKS-06 30 m³/h DN65
PN16
R 3/4" BSP inner thread
980 cm²
、濾芯 DELTA-SKS-08 45 m³/h DN80
PN16
R 3/4" BSP inner thread
1870 cm²
、濾芯 DELTA-SKS-10 70 m³/h DN100
PN16
R 3/4" BSP inner thread
1870 cm²
、濾芯 DELTA-SKS-12 120 m³/h PN16
DN125
R 3/4" BSP inner thread
2750 cm²
、濾芯 DELTA-SKS-15 160 m³/h DN150
PN16
R 3/4" BSP inner thread
2750 cm²
、濾芯 DELTA-SKS-20 280 m³/h DN200
PN16
R 3/4" BSP inner thread
8100 cm²
、濾芯 DELTA-SKS-25 430 m³/h PN16
DN250
R 3/4" BSP inner thread
8100 cm²
Type Flow rate* at 50-100 µm In-/Outlet Drain Filter area
、濾芯 DELTA-SKB-20 300 m³/h DN200
PN16
R 2" BSP outer thread
5800 cm²
、濾芯 DELTA-SKB-25 480 m³/h PN16
DN250
R 2" BSP outer thread
5800 cm²
、濾芯 DELTA-SKB-30 600 m³/h PN16
DN300
R 2" BSP outer thread
11310 cm²
、濾芯 DELTA-SKB-35 800 m³/h PN16
DN350
R 2" BSP outer thread
11310 cm²
、濾芯 DELTA-SKB-40 1000 m³/h PN16
DN400
R 2" BSP outer thread
17430 cm²
、濾芯 DELTA-SKB-45 1400 m³/h PN16
DN450
R 2" BSP outer thread
17430 cm²
、濾芯 DELTA-SKB-50 2000 m³/h PN16
DN500
R 2" BSP outer thread
24600 cm²
